7 Inch 10000psi High-Temperature Squeeze Packer and Drillable Bridge Plug for Oil Well Cementing

Name: 7 Inch 10000psi HighTemperature Squeeze Packer and Drillable Bridge Plug for Oil Well Cementing
Brand: ZZ TOP OIL TOOLS
Price: 1 USD

Quality 7 Inch 10000psi High-Temperature Squeeze Packer and Drillable Bridge Plug for Oil Well Cementing for sale

Brand Name : ZZ TOP OIL TOOLS

Model Number : SVB Squeeze Packer

Certification : ISO, API

Place of Origin : China

MOQ : 1 set

Price : USD 1-10000/set

Payment Terms : L/C,T/T,D/P

Supply Ability : 10 set/month

Delivery Time : 30-50 days

Packaging Details : Pollywood

Product : SVB Squeeze Packer

Application : Oil Well Cementing Operation

Usage : Well Pressure Control

Size : 7 inch

Working Pressure : 10000psi

Connection : IF

Working Condition : Oil & Gas & H2S service

Working Temperature : Up to 425oF

Contact Now

Squeeze Packer / Drillable Bridge Plug / Cement Retainers

The Squeeze Packer is a kind of high-temperature/high-pressure sliding-valve used in remedial cementing operations, also the SVB can be used as the drillable bridge plug and cement retainers. The packers consist of cast iron, brass, aluminum, and rubber to provide unsurpassed drillability. The squeeze packer can control flow and pressure differential in either direction and allows pressure testing of workstring. The slips of the SVB Squeeze Packer allow the packer to be set in all grades of casing.

Operation of Squeeze Packer / EZ SVB Packer

By installing a squeeze packer and opening the sliding valve, you can convert any SVB Squeeze Packer into a top-drilling bridge plug.
A properly converted SVB Bridge Plug has the top-drilling feature, this feature allows pressure to vent across the set bridge plug before the drilling/milling process removes the top slips. This venting eliminates forces from the plug that could otherwise slow the drilling process.

Technical parameter of SVB Squeeze Packer

Applicable Casing size	6 5/8"17-24# 7" 20-38# 7 5/8” 45.3-55.3# 7 3/4"53.52#
Max. Casing ID	164.1mm
Max. OD	139.7mm
Length	802mm
Max. Differential Pressure	10000psi
Working Temperature	-29°℃~120C
Tension Sleeve Value	40000lbs/ 25000lbs/ 30000lbs

7 Inch 10000psi High-Temperature Squeeze Packer and Drillable Bridge Plug for Oil Well Cementing

Product Tags:

7 Inch 10000psi High-Temperature Squeeze Packer and Drillable Bridge Plug for Oil Well Cementing Images
